Solar System Size & Cost in Perth: 6.6kW vs 10kW vs 13kW

For a Perth home in 2026 the three sizes that matter are 6.6kW (around $4,200–$8,900), 10kW ($6,300–$12,600) and 13kW ($10,500–$16,800). The right one is set by how much power you use and when - not by how much roof you have.
Quick answer — residential solar system size and cost in Perth
| System size | Typical Perth installed price (2026) | Panels (≈440 W) | Suited daily usage |
|---|---|---|---|
| 6.6 kW | $4,200–$8,900 | ~15 panels | 15 – 25 kWh/day |
| 10 kW | $6,300–$12,600 | ~23 panels | 25 – 40 kWh/day |
| 13 kW | $10,500–$16,800 | ~30 panels | 40 – 60 kWh/day |
The system rows in our Perth solar table, installed, after the federal STC discount on panels.
You're in.
A local installer will be in touch about your job. No spam, no call centre.
For a Perth home in 2026 the three sizes that matter are 6.6 kW, 10 kW and 13.2 kW. Those tiers cover almost every rooftop in the metro area, from a courtyard home in Subiaco to a large family house in the northern or southern corridors. Anything materially larger — the 40 kW and 50 kW systems you may see advertised — is commercial and industrial territory, sized for warehouses and businesses, and is out of scope for a residential rooftop. This guide stays on the three residential tiers.
What separates the three sizes
1. Price per kilowatt at each size
The fixed costs of a solar install — scaffolding or roof access, the inverter, the switchboard work, the paperwork and the Western Power application — barely change between a 6.6 kW and a 10 kW system, so spreading them over more panels holds the price per kilowatt down. In our Perth table a 6.6 kW system works out at $636–$1,348 per kW installed ($4,200–$8,900 ÷ 6.6). At the typicals a 10 kW system comes in a little lower per kW ($945, from $9,450 ÷ 10) than a 6.6 kW ($955, from $6,300 ÷ 6.6), while a 13 kW is higher again ($1,050, from $13,650 ÷ 13). That is why jumping from 6.6 kW to 10 kW buys the extra capacity for about the same price per kilowatt, and why undersizing is usually a false economy if your roof and finances have the room.
2. Panels and roof area
At today's typical 440 W panels, a 6.6 kW system is about 15 panels and needs roughly 30 m² of unshaded roof; a 10 kW system is about 23 panels and 45 m²; a 13.2 kW system is about 30 panels and close to 60 m². Perth's generally simple tile and Colorbond roofs make panel layout easy compared with steeper or more cut-up roofs elsewhere, but orientation still matters — north-facing pitches produce most, west-facing pitches earn more under the afternoon DEBS peak, and shaded or south-only roofs may push you to optimisers or a smaller array.
3. Single-phase vs three-phase in WA
This is the constraint that catches Perth homeowners out. Most older metro homes are single-phase. Western Power's connection rules generally allow a single-phase home to run an inverter up to 5 kW with standard export — which is why the 6.6 kW system (6.6 kW of panels on a 5 kW inverter) is the default Perth install. Stepping up to 10 kW or 13.2 kW usually means one of two things: your home already has three-phase power (common in newer and larger builds), or you accept an export-limited single-phase setup where the system still powers your home and charges a battery but caps how much it pushes back to the grid. A good installer checks your supply type and your meter before quoting a larger system — if a 10 kW quote does not mention your phase configuration, ask.

Which size suits which household
| Household profile | Sensible size |
|---|---|
| Couple or small family, modest daytime use, no EV | 6.6 kW |
| Family home, ducted air-con, pool pump, one EV coming | 10 kW |
| Large home, high after-dark load, EV(s), planning a battery | 13.2 kW (often three-phase) |
The right size is set by how much power you use and when, not by how much roof you have. A 6.6 kW system comfortably covers a typical Perth couple or small family and is the most common install for good reason. Step up to 10 kW if you run ducted air-conditioning through summer, have a pool, or expect an electric vehicle — the extra generation gives you headroom to self-consume more and to add a battery later without re-engineering. The 13.2 kW tier is for genuinely high-use homes, usually with three-phase supply; on a single-phase home it only makes sense if you are export-limiting and storing the surplus rather than spilling it to the grid for a few cents.
Frequently asked questions
What size solar system do I need in Perth?
Most Perth households suit 6.6kW - it covers a typical couple or small family and fits single-phase supply. Step up to 10kW if you run ducted air-conditioning, a pool, or expect an electric vehicle. 13.2kW suits large, high-use homes, usually with three-phase power.
How much is a 6.6kW solar system in Perth?
A 6.6kW system typically costs $4,200–$8,900 installed in 2026, net of the federal STC discount, and premium panels are $6,800–$11,000 in our Perth table. It is about 15 panels and needs roughly 30 square metres of unshaded roof.
Can I run a 13kW system on single phase in WA?
Usually not at full export. Western Power generally allows a single-phase home an inverter up to 5kW with standard export, which is why 6.6kW is the Perth default. A 10kW or 13.2kW system normally needs three-phase supply, or an export-limited single-phase setup that caps how much you send back to the grid.
Is a bigger system better value per kilowatt?
Up to a point. Fixed costs - access, inverter, paperwork - barely change with size, so at the typicals in our Perth table a 10kW system works out at $945 per kW ($9,450 ÷ 10) against $955 for a 6.6kW ($6,300 ÷ 6.6), provided your roof and supply allow it. A 13kW comes in higher, at $1,050 per kW ($13,650 ÷ 13), so bigger is not automatically cheaper per kilowatt.
